Responsible Disclosure Grafana
Summary of my responsible disclosure work reporting open redirect issues (CVE-2025-4123) that I reported
Executive Summary
During a responsible disclosure engagement, an exposed Grafana instance was identified on the target’s infrastructure.
The version in use was found to be vulnerable to CVE-2025-4123, a severity flaw that combines path traversal and open redirect.
If left unpatched, this issue could allow attackers to redirect users to malicious websites, potentially leading to phishing, data theft, or further exploitation.
Impact
Unauthenticated attackers could trick victims into following trusted links that redirect to malicious domains.
The vulnerability was responsibly reported to the affected organisation. No data was accessed or modified during testing, and all actions were performed strictly within the boundaries of ethical security research.
Enumeration & Introduction
During reconnaissance, the target’s infrastructure was mapped using subdomain enumeration and HTTP probing.
This process led to the identification of an exposed Grafana instance.
Further testing under responsible disclosure confirmed that the instance was running a version of Grafana vulnerable to CVE-2025-4123.
This vulnerability, already disclosed publicly, enables a path traversal that can be exploited for open redirect.
If left unpatched, such vulnerabilities can lead to phishing, credential theft, or further exploitation when chained with other flaws.
Manual Proof of Concept (PoC)
The following request demonstrates a manual open redirect exploit:
http://127.0.0.1:3000/public/..%2F%5cexample.com%2F%3f%2F..%2F..
When visited, this forces the browser to redirect to example.com.
Example output
[*] Redirect triggered: http://example.com/
This confirms the open redirect was successful. It’s a key part of the Proof of Concept because it shows the server was forced to redirect the browser to the attacker controlled example.com. This proves that the vulnerability works as intended.
Acknowledgements
- A special thanks to ynsmorszat for his work on the public CVE-2025-4123 exploit tool!
References
Conclusion
The tested Grafana instance was confirmed to be vulnerable to CVE-2025-4123. Although the issue had already been disclosed publicly, its presence on a production system demonstrates the importance of timely patching. If left unresolved, attackers could potentially escalate from open redirect to SSRF, LFI, or XSS.
Responsible Disclosure: This finding was tested for a live site and responsibly reported to the affected organisation through their Responsible Disclosure program.
Misuse against systems without permission is illegal.
